R22 Hemetic Scroll Compressor 4.5HP R22-B6 60HZ 208 -230V C-SB353H6B

Ask Lasest Price
Brand Name :	SANYO
Model Number :	C-SB353H6B
Certification :	CE
Price :	discussed
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	5000pcs/year
Delivery Time :	5-7days

Add to Cart

Product Details
Company Profile

R22 Hemetic Scroll Compressor 4.5HP R22-B6 60HZ 208 -230V C-SB353H6B

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B R22 scroll compressor for aircondition

Main features

C-SB Series 3--7HP

1. High & low pressure baffle

2. Low sound float valve

3. Tip seal made of PPS

4. Direct power breakdown for motor protection

5. PTEE bearing:bronze with Tefion

6. R22/R407C/R134A/R410A

C-SC Series 8-15HP

1. High reliablity

2. High-performance rolling bearing is applied in the main frame and the bearing plate

3. Direct power breakdown for motor protection

4. The using of strainer in the suction inlet ensures

5. R22/R407C/R134A/R410A

R22-B6(60HZ 208 -230V)
PH	Out put	Displacemert	Compressor Model	Compressor Code	Starting Method	60HZ				Outline Graph Code
	Out put	Displacemert				Capacity		COP
	HP	cm³/rev				kw	KBTU/h	W/W	BTU/Wh
1	3.5	51.8	C-SB261H6C	809 832 46	CSR	11.2	38.2	3.11	10.6	A
	3.5	55.7	C-SB261H6A	809 830 46	CSR	12.1	41.3	3.23	11	A
	4	66.8	C-SB301H6B	809 841 46	CSR	14.5	49.5	3.26	11.1	A
	4.5	77.4	C-SB351H6A	809 842 46	CSR	16.8	57.4	3.2	10.9	As
	5	83.2	C-SB371H6A	809 850 46	CSR	18	61.5	3.13	10.7	A
3	3.5	51.87	C-SB263H6C	809 832 86		11.1	37.9	3.13	10.7	A
	3.5	55.7	C-SB263H6B	809 831 86		11.9	40.6	3.22	11	A
	4	66.8	C-SB303H6A	809 840 86		14.4	49.2	3.27	11.2	As
			C-SB303H6B	809 841 86		14.4	49.2	3.27	11.2	A
			C-SB303H6G	809 846 86		14.4	49.2	3.27	11.2	At
	4.5	77.4	C-SB353H6B	809 843 86		16.8	57.4	3.29	11.2	A
	4.5	77.4	C-SB353H6C	809 844 86		16.8	57.4	3.29	11.2	A
	5	83.2	C-SB373H6A	809 850 86		18.1	61.8	3.32	11.3	As
			C-SB373H6B	809 851 86		18.1	61.8	3.32	11.3	A
			C-SB373H6G	809 856 86		18.1	61.8	3.32	11.3	At
	6	100	C-SB453H6A	809 860 86		21.3	72.7	3.25	11.1	As
			C-SB453H6B	809 861 86		21.3	72.7	3.25	11.1	A
			C-SB453H6G	809 866 86		21.3	72.7	3.25	11.1	At
	7	110.2	C-SBR235H36A			23.3	79.6	3.28	11.2	As
	7	110.2	C-SBR235H36B			23.3	79.6	3.28	11.2	At
	8	131.9	C-SC583H6H	809 284 86		27.9	95.3	3.19	10.9	D
		137	C-SC603H6H	809 281 86		29.6	101.1	3.31	11.3	D
		137	C-SC603H6K	809 283 86		29.6	101.1	3.31	11.3	Dt
	9	148.8	C-SC673H6H	809 291 86		32.3	110.3	3.38	11.5	E
	10	171.2	C-SC753H6H	809 201 86		37	126.3	3.36	11.5	E
	10	171.2	C-SC753H6K	809 203 86		37	126.3	3.36	11.5	Et
	12	205.4	C-SC903H6H	809 221 86		43.2	147.5	10.8	10.8	E

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor

4.5HP R22-B6 60HZ 208 -230V C-SB353H6B scroll compressor
