10hp Sanyo Compressor C-SC753H9H , Sanyo Refrigerator Compressor R22

Ask Lasest Price
Brand Name :	SANYO
Model Number :	C-SC753H9H
Certification :	CE
Price :	discussed
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	1000PCS
Delivery Time :	1-7DAYS

Add to Cart

Product Details
Company Profile

10hp Sanyo Compressor C-SC753H9H , Sanyo Refrigerator Compressor R22

10hp sanyo compressor C-SC753H9H,sanyo refrigerator compressor,sanyo compressor r22

1),No need for expensive and complicated high power inverters and therefore no electromagnetic interferences.

2),Optimum system oil: Digital scroll compressors run at full speed at all time, neer slowing or stopping oil flow to the bearings.

3),Superior humidity and temperature control for improved human comfort.

4),Highest performance at full load.

5),Precise suction pressure control with associated energy savings.

Product Name	10HP air conditioner and scroll type Sanyo compressor C-SC753H9H
Material	stainless steel
Cooling capacity	37300 W
Voltage	380 V/3/60Hz
Refrigerant	R22
Weight	70 Kg
Dimension	0.025 CBM
Leading time	About 10 days once the order is confirmed

C-SC753H9H			Compressor
Application			Type		Hermetic Scroll
Evaporating Temp Range	(℃)	-15~12	Displacement	(cm3/rev)	51.8
Refrigerant		R22	Suction Line Connection	(Φmm OD)	22.23
Compressor Cooling		Natural Cooling	Discharge Line Connection	(Φmm OD)	12.7
Rated Performance			Oil Type		L-DRC/B56
Capacity	(W)	10900	Initial Oil Charge	(ml)	1700
Input	(W)	3600	Mass(Incl.Oil)	(kg)	36.5
Current	(A)	6.08	Motor
Sound Pressure Level(1m)	(dB(A))	62max	Motor Type		3Ph-Induction Motor
Rating Conditions			Revolution	(min-1)	3500
Power Source		3ph,60Hz,380V	Voltage Range	(V)	342~418
Evaporating Temp	(℃)	7.2	Start Capacitor	MFD/V	n/a
Condensing Temp	(℃)	54.4	Run Capacitor	MFD/V	n/a
Suction Gas Temp	(℃)	18.3	RLA	(A)	7.8
Liquid Temp	(℃)	46.1	MCC	(A)	28.1
Ambient Temp	(℃)	35	LRA	(A)	101

10hp Sanyo Compressor C-SC753H9H , Sanyo Refrigerator Compressor R22

R22 60HZ 2380V			compressor model	Compressor Code	60HZ
phase	out put HP	displacement Cm3/rev			KW	kBTU/H	W/w	BTU/WH
phase	out put HP	displacement Cm3/rev			Capacity		COP
3	3.5	51.8	C-SB263H9B	809 831 89	10.9	37.2	3.03	10.3
		55.7	C-SB263H9C	809 832 89	10.9	37.2	3.03	10.3
		55.7	C-SB263H9A	809 830 89	11.8	40.3	2.98	10.2
	4	66.8	C-SB303H9A	809 840 89	14.2	48.5	3.23	11
	4	66.8	C-SB303H9G	809 846 89	14.2	48.5	3.23	11
	4.5	77.4	C-SB373H9A	809 842 89	16.6	56.7	3.25	11.1
	5	83.2	C-SB373H9A	809 850 89	17.8	60.8	3.24	11.1
	5	83.2	C-SB373H9G	809 856 89	17.8	60.8	3.24	11.1
	6	100	C-SB453H9A	809 860 89	21.2	72.4	3.24	11.1
	6	100	C-SB453H9G	809 866 89	21.2	72.4	3.24	11.1
	7	110.2	C-SBR235H39A		23.4	79.9	3.3	11.3
	7	110.2	C-SBR235H9B		23.4	79.9	3.3	11.3
	8	137	C-SC603H9H	809 281 89	29.6	101.1	3.29	11.2
	8	137	C-SC603H9K	809 283 89	29.6	101.1	3.29	11.2
	10	171.2	C-SC753H9H	809 201 89	37.3	127.3	3.36	11.5
	10	171.2	C-SC753H9K	809 203 89	37.3	127.3	3.36	11.5
	12	205.4	C-SC903H9H	809 221 89	44.4	151.6	3.31	11.3

10hp Sanyo Compressor C-SC753H9H , Sanyo Refrigerator Compressor R22
