Air conditioner Maneurop Piston Refrigeration Compressor MT125HU4DVE with gas R22

Ask Lasest Price
Brand Name :	(Maneurop)
Model Number :	MT-125
Certification :	CE, ROHS
Price :	discussed
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	5,000pcs per month
Delivery Time :	7-10 working days after receiving payment

Add to Cart

Product Details
Company Profile

Air conditioner Maneurop Piston Refrigeration Compressor MT125HU4DVE with gas R22

Maneurop piston compressor MT-125 with gas R22 Air conditioner compressor

Specification:

Maneurop MT/MTZ series compressors are of the hermetic reciprocating type and are designed for Medium and high evaporating temperature applications.

There are 26 different models with displacement ranging from 30-543cm3/rev.

Our Maneurop compressors are for 50Hz, motor code is 4, can be used for R22/R407C/R134a/R404A/R507

1. Piston /reciprocating type compressors.

2. Voltage is 50Hz

3. The refrigerant are R22/R407C/R134a/R404A/R507

4. There are MT/MTZ series

5. Original from France.

6.Capacity: 1.5HP~13HP, High efficiency, Low noise

1.MT series for R134a

2. MTZ series for R407c/134a

1.50 Hz

2. Imported form France.

3.R22 Rated condition:50Hz/400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C

4.R407C Rated condition :50Hz 400V

superheat:11.1K

subcooling 8.3K condensing temp:54.4°C

evaporating temp.7.2°C

refrigeration and power input±5%

We can supply more compressor models as below:

Compressor Model	Swept Volume	Displacement		Nomimal Ratings*				Number of Cylinders	Oil Charge Litre	Net Weight kg
		50Hz 2900 rpm m/hr	60Hz 3500rpm m/hr	50Hz		60Hz
		50Hz 2900 rpm m/hr	60Hz 3500rpm m/hr	Cooling Capacity W	COP W/W	Cooling Capacity W	COP W/W
NTZ048	48	8.4	10.1	995	1.15	1190	1.13	1	0.95	21
NTZ068	68	11.8	14.3	1749	1.15	1870	1.1	1	0.95	23
NTZ096	96	16.7	20.2	2002	1.15	2395	1.16	2	1.8	35
NTZ108	108	18.7	22.6	2465	1.16	2788	1.1	2	1.8	35
NTZ136	136	23.6	28.5	3225	1.11	3739	1.12	2	1.8	35
NTZ215	215	27.5	45.2	4948	1.19	5886	1.19	4	3.9	62
NTZ271	271	47.3	57	6955	1.24	8058	1.21	4	3.9	64
(*)Motor code 4 operating Conditions:R404a,Evap.Temp.:-35°C,Cond.temp.:40°C,RGT:20°C.SC:0k

MODEL (R22)	MODEL (R404A)	NTZ series
MT18-4VM	MTZ18-4VM	NTZ048A4LR1A
MT22-4VM	MTZ22-4VM	NTZ068A4LR1A
MT28-4VM	MTZ28-4VM	NTZ096A4LR1A
MT32-4VM	MTZ32-4VM	NTZ108A4LR1A
MT36-4VM	MTZ36-4VM	NTZ136A4LR1A
MT40-4VM	MTZ40-4VM	NTZ215A4LR1A
MT44-4VM	MTZ44-4VM	NTZ271A4LR1A
MT50-4VM	MTZ50-4VM
MT56-4VM	MTZ56-4VM
MT64-4VM	MTZ64-4VM
MT72-4VM	MTZ72-4VM
MT80-4VM	MTZ80-4VM
MT100-4VM	MTZ100-4VM
MT125-4VM	MTZ125-4VM
MT144-4VM	MTZ144-4VM
MT160-4VM	MTZ160-4VM

Model NO.	Nom HP	Displ. Cc/rev	Capacity R404a(w)
Model NO.	Nom HP	Displ. Cc/rev	-10	-5
MTZ18-4VI	1.5	30.2	1580	2110
MTZ18-5VI	1.5	30.2	1580	2110
MTZ22-4VI	1.8	38.12	2270	2920
MTZ22-5VI	1.8	38.12	2270	2920
MTZ28-4VI	2.3	48.06	2880	3720
MTZ28-5VI	2.3	48.06	2880	3720
MTZ32-4VI	2.7	53.86	3230	4220
MTZ32-5VI	2.7	53.86	3230	4220
MTZ36-4VI	3	60.47	3800	4870
MTZ36-5VI	3	60.47	3800	4870
MTZ40-4VI	3.3	67.89	4280	5490
MTZ45-4VI	3.8	76.22	4420	5840
MTZ51-4VI	4.2	85.64	5290	6920
MTZ57-4VI	4.8	96.13	6060	7880
MTZ65-4VI	5.4	107.71	7080	9130
MTZ73-4VI	6.1	120.94	7960	10230
MTZ81-4VI	6.8	135.78	9160	11720
MTZ100-4VI	8.3	171.26	10390	13500
MTZ125-4VI	10.4	215.44	13650	17500
MTZ144-4VI	12	241.87	15740	20120
MTZ160-4VI	13.3	271.55	17690	22520

Code no.	HP	MT-R22			MTZ-R407C			MTZ-R134a			MTZ-R404
Code no.	HP	Kw	BTUH	EER	Kw	BTUH	EER	Kw	BTUH	EER	Kw	BTUH	EER
MT/MTZ18	1.5	1.74	15900	9.15	1.67	15300	9.13	1.22	11200	9.2	1.76	10300	5.1
MT/MTZ22	2	2.27	22000	9.68	2.17	19600	9	1.54	14800	9.63	2.05	14100	6.01
MT/MTZ28	2.5	3.07	30200	9.86	2.83	25100	8.9	2.04	19300	9.42	2.68	18300	5.96
MT/MTZ32	2.75	3.58	33000	9.22	3.21	28400	8.86	2.39	20900	8.76	2.99	20100	5.85
MT/MTZ36	3	4.05	38000	9.38	3.75	32700	8.73	2.75	24500	8.91	3.34	23200	6.05
MT/MTZ40	3.5	4.63	42900	9.27	4.33	37400	8.64	3.08	27900	9.03	3.77	26400	6.11
MT/MTZ44	4	4.67	45200	9.69	4.37	43000	9.84	3.14	29800	9.51	4.18	27800	6.65
MT/MTZ50	4.5	5.18	50500	9.74	4.96	48100	9.71	3.6	34500	9.57	4.83	32500	6.73
MT/MTZ56	5	6.05	56400	9.32	5.67	54300	9.59	3.95	38000	9.62	5.44	36500	6.71
MT/MTZ64	5.5	6.8	64800	9.53	6.36	60400	9.5	4.68	45300	9.66	6.12	41500	6.78
MT/MTZ72	6	7.58	70100	9.26	7.22	67900	9.41	5.19	50000	9.63	6.91	46500	6.72
MT/MTZ80	7	8.56	80000	9.35	8.24	76900	9.33	6	56500	9.42	8.03	52500	6.54
MT/MTZ100	9	9.59	95900	10	9.9	94400	9.53	6.5	63900	9.84	8.72	60800	6.07
MT/MTZ125	10	12.81	124600	9.73	12.62	122100	9.67	7.72	78900	10.2	11.37	78400	6
MT/MTZ144	12	14.36	140700	9.8	14.47	137200	9.48	9.82	96900	9.87	13	92300	6.19
MT/MTZ160	13.5	16.09	156800	9.75	16.67	155100	9.31	10.92	107600	9.85	14.74	100300	5.93
