Thermostatic expansion Valves Model TDE/TDEX TDEBX - R22 TDES - R404A/R507 TDEZ/TDEBZ - R407C TDEN 068H8331

TDE/TDEX TDEBX - R22 TDES - R404A/R507 TDEZ/TDEBZ - R407C

Specifications:

Regriratant:R404A/R22/R507/R407C
Thermostatic expansion valve regulate the flow of refrigerant liquid into The evaporator.
The flow is controlled by the valve is thermal bulb which is Attached to the suction line at the outlet of the evaporator.
The thermal Bulb senses the evaporator heat and adjusts the valve to admit refrigerant Liquid in accordance with the refrigerating load.

Part Number	Model No.	Solder Connection	Nominal Capacity (kW)	Evaporating Temperature: °C
				-30	-20	-10	-5	0	5
				Rated Capacity (kW)
TDE/TDEX & TDEBX - R22
068H7054	TDEX4	1/2 x 7/8	14	6.4	8.5	10.8	12.1	13.5	14.8
068H7058	TDEX6	1/2 x 7/8	21	9.6	12.6	16.2	18.1	20.1	22.1
068H8106	TDEX8	5/8 x 7/8	28	17.8	20.7	24	25.8	27.6	29.5
068H8108	TDEX11	5/8 x 7/8	38	21.9	26.5	31.8	34.6	37.4	40.4
068H8112	TDEX12.5	5/8 x 7/8	44	24.2	29.7	36	39.3	42.7	46.3
068H8116	TDEX16	5/8 x 1-1/8	56	29.3	36.7	45.2	49.7	54.3	59
068H8118	TDEX16	7/8 x 1-1/8	56	29.3	36.7	45.2	49.7	54.3	59
068H7080	TDEBX20#	7/8 x 1-1/8	70	38.6	47.5	57.5	62.9	68.4	74
068H7086	TDEBX30#	1-1/8 x 1-3/8	106	52.7	67.2	83.5	92.5	102	110
068H7088	TDEBX40#	1-1/8 x 1-3/8	140	69	88.4	110	122	135	147
	MODEL TDES - R404A/R507
068H8750	TDES4.4	1/2 x 7/8	15.3	7.8	10.2	12.9	14.3	15.6	16.9
068H8751	TDES5.5	1/2 x 7/8	19.3	9.5	12.5	15.9	17.6	19.3	21.1
068H8752	TDES8.0	5/8 x 7/8	28	16.8	20.4	24.3	26.3	28.3	30.2
068H8753	TDES9.1	5/8 x 7/8	32	18.7	23	27.6	30	32.3	34.4
068H8754	TDES11.7	7/8 x 1-1/8	41	22.7	28.4	34.6	37.8	40.9	43.9
068H8755	TDES13.9	7/8 x 1-1/8	49	26.5	33.4	40.8	44.4	48.8	52
068H8756	TDES14.6	7/8 x 1-1/8	51	29.6	35.4	43.8	47.6	51.3	55
068H8757	TDES19.0	7/8 x 1-3/8	66	36.8	46.1	56.2	61.3	66.5	71.4
068H8758	TDES22.0	7/8 x 1-3/8	75	40.4	51.4	63.3	69.5	75.7	81.7
068H8759	TDES29.0	7/8 x 1-3/8	101	53.7	68.6	84.9	93.3	101.4	110
MODEL TDEZ/TDEBZ - R407C
068H7004	TDEZ4	1/2 x 7/8	14	6.2	8.4	10.8	12.2	13.5	14.9
068H7008	TDEZ6	1/2 x 7/8	21	9.3	12.5	16.2	18.2	20.2	22.3
068H8260	TDEZ8	5/8 x 7/8	28	17.5	20.6	24.1	25.9	27.8	29.7
068H8264	TDEZ11	5/8 x 1-1/8	38.5	21.5	26.3	31.8	34.7	37.7	40.7
068H8268	TDEZ12.5	5/8 x 1-1/8	44	23.8	29.5	36.1	39.5	42.9	46.5
068H8272	TDEZ16	7/8 x 1-1/8	56	28.7	36.4	45.2	49.8	54.6	59.4
068H7030	TDEBZ20#	7/8 x 1-1/8	70	37.9	47.1	57.5	63.1	68.8	74.6
068H7032	TDEBZ26#	7/8 x 1-3/8	91	46.6	59.2	73.4	81	88.8	96.7
068H7036	TDEBZ30#	7/8 x 1-3/8	105	51.5	66.4	83.5	92.7	102	112
068H7038	TDEBZ40#	7/8 x 1-3/8	140	67.4	87.4	110	122	135	148
