    Customizable Refrigerator Condenser Units 2-50 HP Semi Hermetic Condensing Unit

    Ask Lasest Price
    Model Number : All models
    Certification : CE
    Price : discussed
    Payment Terms : T/T or western Union
    Supply Ability : 3,000pcs per month
    Delivery Time : 7-10 working days after received your payment
    • Product Details
    • Company Profile

    Customizable Refrigerator Condenser Units 2-50 HP Semi Hermetic Condensing Unit

    Refrigerator Condenser Units 2-50HP Semi Hermetic Condensing Unit
    Air cooled Condensing Unit for cold storage room

    Specifications:
    A 2HP low-temperature semi-hermetic condensing unit using Bitzer compressors is designed for commercial refrigeration applications. Here are the general specifications for such a unit, though specific models may vary:

    General Specifications:

    1. Compressor:

      • Brand: Bitzer(Customizable)
      • Type: Semi-hermetic
      • Horsepower: 2HP
      • Displacement: Varies by model, typically around 10-15 m³/h
      • Refrigerant: Suitable for R404A, R507, R22, or other low-temperature refrigerants
      • Operating Temperature: Typically ranges from -25°C to -40°C
    2. Condensing Unit:

      • Condensing Type: Air-cooled
      • Cooling Capacity: Approximately 4-7 kW (varies based on ambient conditions and refrigerant)
      • Voltage: Usually available in 220V/380V, 50Hz or 60Hz (depending on region)
      • Fan: High-efficiency axial fan(s)
      • Coil Material: Copper tubes with aluminum fins for efficient heat exchange
      • Number of Fans: Typically 1 or 2 fans, depending on model
      • Noise Level: Low noise, usually around 50-60 dB
    3. Other Features:

      • Control System: Equipped with high and low-pressure switches, thermostat, and safety devices
      • Oil Separator: Included to improve efficiency and protect the compressor
      • Receiver: Liquid receiver included to store refrigerant
      • Expansion Valve: Thermostatic expansion valve fitted for efficient refrigerant control
      • Pressure Gauges: For monitoring suction and discharge pressures
    4. Dimensions and Weight:

      • Size: According to different working conditions and sizes, customized multi-parallel connection can be supported
      • Weight: Around 100-150 kg, depending on the specific configuration
    5. Applications:

      • Suitable for low-temperature storage, freezer rooms, cold storage, or other commercial refrigeration systems requiring temperatures down to -40°C.

    If you need detailed specifications for a particular model, you can provide a specific Bitzer compressor model number, and I can help with more tailored data.

    New model Number

    Old model number

    Horse power

    2HES-1

    2HC-1.2

    1HP

    2HES-2

    2HC-2.2

    2HP

    2GES-2

    2GC-2.2

    2HP

    2FES-2

    2FC-2.2

    2HP

    2FES-3

    2FC-3.2

    3HP

    2EES-2

    2EC-2.2

    2HP

    2EES-3

    2EC-3.2

    3HP

    2DES-2

    2DC-2.2

    2HP

    2DES-3

    2DC-3.2

    3HP

    2CES-3

    2CC-3.2

    3HP

    2CES-4

    2CC-4.2

    4HP

    4FES-3

    4FC-3.2

    3HP

    4FES-5

    4FC-5.2

    5HP

    4EES-4

    4EC-4.2

    4HP

    4EES-6

    4EC-6.2

    6HP

    4DES-5

    4DC-5.2

    5HP

    4DES-7

    4DC-7.2

    7HP

    4CES-6

    4CC-6.2

    6HP

    4CES-9

    4CC-9.2

    9HP

    4VES-7

    4VCS-6.2

    6HP

    4VES-10

    4VCS-10.2

    10HP

    4TES-9

    4TCS-8.2

    8HP

    4TES-12

    4TCS-12.2

    12HP

    4PES-12

    4PCS-10.2

    10HP

    4PES-15

    4PCS-15.2

    15HP

    4NES-14

    4NCS-12.2

    12HP

    4NES-20

    4NCS-20.2

    20HP

    4JE-15

    4J-13.2*

    13HP

    4JE-22

    4J-22.2*

    22HP

    4HE-18

    4H-15.2*

    15HP

    4HE-25

    4H-25.2*

    25HP

    4GE-23

    4G-20.2*

    20HP

    4GE-30

    4G-30.2*

    30HP

    6JE-25

    6J-22.2*

    20HP

    6JE-33

    6J-33.2*

    33HP

    6HE-28

    6H-25.2*

    25HP

    6HE-35

    6H-35.2*

    35HP

    6GE-34

    6G-30.2*

    30HP

    6GE-40

    6G-40.2*

    40HP

    6FE-44

    6F-40.2*

    40HP

    6FE-50

    6F-50.2*

    50HP
